HARDWARE AND NETWORKING (DIPLOMA)

HARDWARE AND NETWORKING (DIPLOMA)

Basic Electronics:-

The goal of this chapter is to provide some basic information about electronic circuits. We make the assumption that you have no prior knowledge of electronics, electricity, or circuits, and start from the basics. This is an unconventional approach, so it may be interesting, or at least amusing, even if you do have some experience. So, the first question is “what is an electronic circuit?”

Computer Fundamentals:-

Computer is an electronic device i.e. used to work with information or compute. It is derived from the Latin word “computare” which means to calculate.Our Computer fundamentals tutorial includes all topics of Computer fundamentals such as input devices, output devices, memory, CPU, motherboard, computer network, virus, software, hardware etc.

Computer Peripherals:-A computer peripheral is a device that is connected to a computer but is not part of the core computer architecture. The core elements of a computer are the central processing unit, power supply, motherboard and the computer case that contains those three components. Technically speaking, everything else is considered a peripheral device. However, this is a somewhat narrow view, since various other elements are required for a computer to actually function, such as a hard drive and random-access memory (or RAM).

Most people use the term peripheral more loosely to refer to a device external to the computer case. You connect the device to the computer to expand the functionality of the system. For example, consider a printer. Once the printer is connected to a computer, you can print out documents. Another way to look at peripheral devices is that they are dependent on the computer system. For example, most printers can’t do much on their own, and they only become functional when connected to a computer system.

Types of Peripheral Devices

There are many different peripheral devices, but they fall into three general categories:

  1. Input devices, such as a mouse and a keyboard
  2. Output devices, such as a monitor and a printer
  3. Storage devices, such as a hard drive or flash drive

Assembling/Dissembling of a PC:- The assembling of the computer system is exactly the opposite of disassembling operation. Before starting assembling the computer system, make sure you have the screws and a screwdriver for those.

The first step for assembling the computer system starts with mounting the processor on the processor socket of the motherboard. To mount the process, you don’t need to apply any force. The special ZIF (zero insertion force) sockets are usually used to prevent any damage to the processor pins. Once the processor is mounted, the heat sink will be attached on top of the processor. The CPU fan is also attached on top of the heat sink.

Now the motherboard is to be fixed vertically in the tower case and the screws are fixed from behind of the motherboard.

Now line up the power supply at the top back end of the cabinet and screw it. The power connectors for motherboard power supply and CPU fan power supply are to be connected. If the cabinet cooling FAN is required then it is to be screwed at the back end grill of the cabinet and its power connector is to be connected from SMPS.

Install the CD/DVD drives at the top front end of the cabinet and screw it. Install the Hard disk drive and floppy disk drive below CD/DVD drive and screw it. Make sure once screwed there is no vibration in either of the CD/DVD, Hard disk or Floppy disk drives.

Now select the appropriate data cable and connect one end of the cable to its drive socket and another end at its appropriate connector on the motherboard. For SATA hard disk drive or CD/DVD drives use SATA cable and its power cable, else use IDE data cable. Do the proper jumper settings as per the usage requirement.

It is time now to mount the memory modules on the motherboard by aligning the RAM to its socket on the motherboard and press it downward. Make sure the side tab are fixed into the RAM notch. If not, you may still have to press a bit.

Install the internal cards to its socket and attach the cables or power cable to it. The selection of right socket or slot is required as per the type of socket.

Cover the tower by placing it and pressing towards front side and screw it.

Connect the external devices with CPU at its appropriate socket. It includes mouse and keyboard at PS2 or USB connectors. Monitor at the video output socket. Connect the power cable to the back of tower in SMPS. Plug in the power cable to the electric board.

Troubleshooting PC:-roubleshooting is a form of problem solving, often applied to repair failed products or processes on a machine or a system. It is a logical, systematic search for the source of a problem in order to solve it, and make the product or process operational again. Troubleshooting is needed to identify the symptoms. Determining the most likely cause is a process of elimination—eliminating potential causes of a problem. Finally, troubleshooting requires confirmation that the solution restores the product or process to its working state.

In general, troubleshooting is the identification or diagnosis of “trouble” in the management flow of a system caused by a failure of some kind. The problem is initially described as symptoms of malfunction, and troubleshooting is the process of determining and remedying the causes of these symptoms.

A system can be described in terms of its expected, desired or intended behavior (usually, for artificial systems, its purpose). Events or inputs to the system are expected to generate specific results or outputs. (For example, selecting the “print” option from various computer applications is intended to result in a hardcopy emerging from some specific device). Any unexpected or undesirable behavior is a symptom. Troubleshooting is the process of isolating the specific cause or causes of the symptom. Frequently the symptom is a failure of the product or process to produce any results. (Nothing was printed, for example). Corrective action can then be taken to prevent further failures of a similar kind.

The methods of forensic engineering are useful in tracing problems in products or processes, and a wide range of analytical techniques are available to determine the cause or causes of specific failures. Corrective action can then be taken to prevent further failure of a similar kind. Preventative action is possible using failure mode and effects (FMEA) and fault tree analysis (FTA) before full-scale production, and these methods can also be used for failure analysis.

  • Window Management / User Management:-A window manager is system software that controls the placement and appearance of windows within a windowing system in a graphical user interface. Most window managers are designed to help provide a desktop environment.

User management is a core part to any directory service and is a basic security essential for any organization. User management enables admins to control user access and on-board and off-board users to and from IT resources
